Compatible 622Gb/s 850nm SFP Optical Transceivers 550M with PIN photo detector

Compatible 622Gb/s 850nm SFP Optical Transceivers 550M with PIN photo detector

Quick Detail:

Applications:

1. Switch to Switch Interface
2. Fast Ethernet
3. Switched Backplane Applications
4. Router/Server Interface
5. Other Optical Links

PRODUCT DESCRIPTION

GB-LINK’s GB-SFP-1285-5 Small Form Factor Pluggable (SFP) transceivers are compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA). The transceiver consists of five sections: the LD driver, the limiting amplifier, the digital diagnostic monitor, the VCSEL laser and the PIN photo-detector .The module data link up to 550m in 50/125um multi mode fiber.

The optical output can be disabled by a TTL logic high-level input of Tx Disable, and the system also can disable the module via I2C. Tx Fault is provided to indicate that degradation of the laser. Loss of signal (LOS) output is provided to indicate the loss of an input optical signal of receiver or the link status with partner. The system can also get the LOS (or Link)/Disable/Fault information via I2C register access.

PRODUCT FEATURES

1. Up to 622Gb/s data links with DDM
2. VCSEL laser transmitter and PIN photo-detector
3. Up to 550m on 50/125µm MMF
4. Hot-pluggable SFP footprint
5. Duplex LC/UPC type pluggable optical interface
6. Low power dissipation
7. Metal enclosure, for lower EMI
8. RoHS compliant and lead-free
9. Single +3.3V power supply
10. Compliant with SFF-8472
11. Case operating temperature

                    Commercial: 0°C to +70°C

                    Extended: -10°C to +80°C

                    Industrial: -40°C to +85°C

Competitive advantage:


1. High reliability and consistency
2. Good pricing
3. Full compatible (CISCO/HP/Extreme/Juniper/H3C…)
4. OEM/ODM  Customized label
5. Fast delivery
