550M Juniper multi mode SFP Fiber Optical Transceiver with Metal enclosure

550M Juniper multi mode SFP Fiber Optical Transceiver with Metal enclosure

Quick Detail:

Applications:

1. Switch to Switch Interface
2. Fast Ethernet
3. Switched Backplane Applications
4. Router/Server Interface
5. Other Optical Links

PRODUCT DESCRIPTION

GB-LINK’s GB-SFP-1213-5 Small Form Factor Pluggable (SFP) transceivers are compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA). The transceiver consists of five sections: the LD driver, the limiting amplifier, the digital diagnostic monitor ,the FP laser and the PIN photo-detector. The module data links up to 550M in 50/125 um multi mode fiber.

The optical output can be disabled by a TTL logic high-level input of Tx Disable, and the system also can disable the module via I2C. Tx Fault is provided to indicate that degradation of the laser. Loss of signal (LOS) output is provided to indicate the loss of an input optical signal of receiver or the link status with partner. The system can also get the LOS (or Link)/Disable/Fault information via I2C register access.

PRODUCT FEATURES

1. Up to 622Mb/s data links
2. FP laser transmitter and PIN photo-detector.
3. Up to 550m on 50/125µm MMF
4. Hot-pluggable SFP footprint
5. Duplex LC/UPC type pluggable optical interface
6. Low power dissipation
7. Metal enclosure, for lower EMI
8. RoHS compliant and lead-free
9. Support Digital Diagnostic Monitoring interface
10. Single +3.3V power supply
11. Compliant with SFF-8472
12. Case operating temperature

                    Commercial: 0°C to +70°C

                    Extended: -10°C to +80°C

                    Industrial: -40°C to +85°C

Competitive advantage:


1. High reliability and consistency
2. Good pricing
3. Full compatible (CISCO/HP/Extreme/Juniper/H3C…)
4. OEM/ODM  Customized label
5. Fast delivery
